يمتد الخط الثاني من محطة شبرا الخيمة في محافظة القليوبية إلى محطة المنيب في محافظة الجيزة بطول حوالى 19 كم و20 محطة. ويوجد به محطتين تبادليتين مع الخط الأول هما محطتى الشهداء والسادات. يتكون الخط من جزء سطحى بطول 6 كم يحتوي على 6 محطات سطحية، وجزء نفقى بطول 9.5 كم يحتوى على 10 محطات تحت الأرض إلى جانب المحطتين التبادليتين.
Cairo's metro network was greatly expanded in the mid-1990s with the building of Line 2 (red), from Shoubra-El-Kheima to Cairo University, with an extension to Giza.
It is the first line in history to have a tunnel going under the Nile.[6][7] The tunnel under the Nile is 8.35m in internal diameter and was constructed using two Herenknecht bentonite slurry shield TBMs, which are 9.43m in diameter.[6] Extending 21.5 kilometres (13 mi) with 20 stations, it is sometimes called the "Japanese-Built Line".[citation needed] It is mostly in bored tunnel, with two exceptions: a short section at the northern end approaching Shubra El-Kheima which is elevated, and a section just south of this by cut-and-cover. The main difference between Lines 1 and 2 is that Line 1 uses an overhead line while Line 2 uses the third-rail system.[citation needed] The construction of the line was finished in October 2000 and was later extended to El Mounib.[6] The communication for line 2 was provided by Alcatel in 2005.[8]
Total project cost was 761 million euros
