Application
Environment Dry Location approved. IP 20.
Mounting C3/C4: Mounts to a 4” octagonal box using the mounting canopy.
Electrical
Power Supplies Remote LED drivers (120-277V AC input, constant current output): Fixtures to be wired in series.
Control On/off control
Dimming: ELV or 0-10V dimming with appropriate drivers.
Other options (consult factory): TRIAC/MLV, DMX, DALI, Casambi, Power over Ethernet.
Luminaire Construction
LED Light Source W22S = CCT: 2200K, CRI (Ra): 80+, Colour Consistency: 3SDCM
Weight N/A
Material Fixture: machined marine-grade aluminum.
Supplied with Standard installation housing: Comes with a canopy, a universal crossbar, two hex socket head screws, two wirenuts, and an allen key OR C21 with two wire connectors.
Warranty & LED Life 5 years limited warranty.
The estimated useful life of LED is 50,000 hours.
