WALL MOUNTED
SLOT UP-DOWN
S.3835W
2 module COB 3000K 220-240Vac DIMMABLE DALI; DALI2; PUSH
Rated module luminous flux:: 7272lm
Rated luminaire luminous flux: : 5073lm
Rated module power: : 56W
Rated luminaire power: : 61.7W
Luminaire efficacy: : 82lm/W
Voltage (AC): : 220-240Vac
Frequency (AC): : 50/60Hz
Voltage (DC): : 176-280Vdc (No PUSH DIM)
Dimmable: : DALI; DALI2; PUSH
PUSH Synchronization:
- Max 4 Luminaires, distance <15m;
- Max 35 Luminaires, distance <300m with S.2490 accessory.
Electrical insulation class: : I
Protection class IP: : IP65
Mechanical resistance: : IK08
CE
LUMINAIRE TYPE
Wall mounted luminaire. IP rating IP 65
