Here is Part 3 in the series. All the moving parts you'll need to bring your model to life with the help of sketchyphysics. The uniquely shaped pistons oscillate around a central stationary pin. The act upon the crankshaft via a stadard conrod. Pretty cool design. The 2D plan it started from is in here too. Be sure to copy and 'paste in place' into pt 1. of the series. Press play and watch it run.
