Application purpose:
- For convenient toilet use
- For gently cleaning the anal area with water
Characteristics:
- WC seat and WC lid with SoftClosing
- WC lid with SoftOpening
- Integrated storage water heater
- Adjustable storage water heater operating mode (ON/OFF/economy mode)
- User detection for water heating
- Washdown WC with dirt-repellent ceramic surface
- Spray arm with nozzle can be extended for anal area
- Spray arm can be set to five different positions
- Spray intensity can be set to five different levels
- Adjustable oscillating spray (automatic forward and reverse motion of the spray arm)
- Automatic pre- and post-rinsing of the spray nozzle with fresh water
- Water supply connection on the left, hidden behind the WC ceramic
- Mains connection with flexible three-wire sheathed cable, on the right side, hidden behind the WC ceramic
- External water supply connection on the left, accessories possible
- External mains connection with power outlet on the right possible
- Most recently used settings are stored automatically
- Approval in accordance with EN 1717 / EN 13077
Technical data:
- Protection classI
- Protection degreeIPX4
- Nominal voltage230 V AC
- Mains frequency50-60 Hz
- Power consumption800 W
- Power consumption standby / with heating switched on0.45/5.8 W
- Flow pressure0.5-10 bar
- Minimum flow pressure0.5 bar
- Operating temperature10-40 °C
- Water temperature, factory setting37 °C
- Calculated flow rate0.04 l/s
- Spray time20 s
- Maximum load WC seat150 kg
Scope of delivery:
- Water supply connection set for Geberit Sigma concealed cistern 12 cm and Geberit Omega concealed cistern 12 cm
- Female socket for mains connection
- Sound insulation set
- Blind plug for WC ceramic appliance
- Compensation pad for WC seat / ceramic appliance
- Spray shield
- Cleaning set
- Remote control with wall-mounted case and battery CR2032
- Fastening material
Article:
146.140.11.1white alpine
